ARINC 818 Switches

ARINC 818 video switching in real-time

TECHWAY (France) & Great River Technology (USA) have join forces to offer a wide range of ARINC 818 switches designed to simplify multi-destination and multi-source architectures.

The ARINC 818 switches are built on the FPGA technology associated with optical interfaces with very high density. All the switches ensure that video frames remain intact and void of corruption during switching.

These solutions are ICD independent. The link rate and virtualization configuration are set at the order.

These switches are used on major aircraft equipment programs.

Category:

Applications

  • Test and measure
  • Prototyping
  • Flight test

Advantages

  • Ready-to-use :
    • Stand-alone use
    • Rackable
  • Easy-to-use :
    • Monitoring and command via Ethernet
    • Easy configuration
    • TECHWAY support
  • Real-time
  • Low-latency switching
  • Low propagation delay
  • Switching virtualization capability

Key Features

  • Link rate available : 1.0625, 2.125, 3.1875 or 4.25 Gbps (others on demand)
  • Optional test pattern (on demand)
  • Power supply (120V – 240V) and DC (48V – 28V)
  • LC optical connectors (850nm)
  • Real-time link monitoring and error counter
  • Embedded Web server for Cmd/Ctrl
  • Low-latency switching
  • Unicast, multicast and broadcast
  • Operating temperature range :
    • Commercial : 0°C to 50°C
    • Rugged : -15°C to 70°C
  • Storage temperature range : -55°C to 125°C
  • CE mark
  • DO160-F compliant

SPIDER specifications

  • Switch control 10/100BaseT Ethernet
  • 10 inputs and 10 outputs channels
  • Embedded SNMP server
  • Several virtual configurations (10×10 or 4×4+6×6 or 2×2+8×8)
  • Format :
    • 1U 19” rack
    • Rugged and DO160-F compliant

PANTERA specifications

  • Switch control 10/100BaseT Ethernet
  • 4 inputs and 4 outputs channels
Manufacturer

Techway
